| Impulse discharge current for class I test (10/350) | Iimp | 50 kA |
| Test class according to EN 61643-11:2012 (IEC 61643-11:2011) | T1 | |
| System | TN-S | |
| Number of poles | 4 | |
| Rated operating AC voltage | UN | 230 V |
| Maximum continuous operating voltage AC | UC | 255 V |
| Total discharge current (10/350) L1+L2+L3+N->PE | ITotal | 200 kA |
| Nominal discharge current for class II test (8/20) | In | 50 kA |
